WHEELTOP EDS-TX Draadloze Carbon Elektronische Shifter/Derailleur (Racefiets)

€659.00 Regular price €879.00
Unit price
per
Stock
Pre-Order Now! 🌟Shipping Begins on June 10th!🎉
Free Shipping
Gratis verzending naar Duitsland, Frankrijk...
Fast 4-Day Delivery

Naar verwachting binnen 2 werkdagen verzonden (Exclusief voorbestellingen)

14-Day Risk free trial
Retourbeleid van 14 dagen
2-Year Warranty
Garantiebescherming van 2 jaar
PAY
Betalingsmogelijkheden

7-13 Speeds
3-14 snelheden
Wireless Connection
Draadloze verbinding
Electronic
Electronic System
Smart APP
Slimme APP
Carbon fiber
Lange batterijduur
IP67 water proof
IP67 waterdicht
形状结合
Snelheid aanpasbaar
U kunt de waarde van elke snelheid finetunen via de WheelTop-app om de meest nauwkeurige en soepele versnellingswisseling te bereiken, speciaal voor u.
Fine-Tune with Ease Super riding experience
You can fine-fune the value of everyspeed through WheelTop app toachieve the most precise and smoothgear shift just for you.
Draadloze Verbinding
Bluetooth en ANT (Adaptief Netwerktopologie) zorgen voor een stabiele draadloze verbinding tussen de controller en derailleur, waardoor een responsieve, soepele en nauwkeurige schakeling mogelijk is. Het draadloze ontwerp maakt installatie gemakkelijker en biedt een ongebonden rit.
路径
路径
Front Derailleur-border
Rear Derailleur-border
line 01
line 02
Elektronisch Derailleur: Effectief rijden
In vergelijking met een mechanische derailleur maakt de elektronische derailleur van Wheeltop het eenvoudig om van snelheid te wisselen. In plaats van één snelheid tegelijk te veranderen, kun je rechtstreeks van 7-speed naar 13-speed schakelen door continu op de knop te drukken, waardoor de efficiëntie in het schakelproces verbetert.
In vergelijking met een mechanische derailleur maakt de elektronische derailleur van Wheeltop het eenvoudig om van snelheid te wisselen. In plaats van één snelheid tegelijk te veranderen, kun je rechtstreeks van 7-speed naar 13-speed schakelen door continu op de knop te drukken, waardoor de efficiëntie in het schakelproces verbetert.
Slimmer fietsen
Fijnafstemmen en schakelen, kalibreren, firmware upgraden, ritgegevens registreren, batterijniveau controleren en modi (leisure of race) schakelen in onze app.
Ritregistratie
Verandering in 3-14 cassettes
Beschikbaar in 9 talen
Batterijstatus controleren
Vrije instelling omhoog/omlaag
Nauwkeurige instelling in elke tandwiel
Beschikbaar in 9 talen
Beschikbaar in 9 talen
Operaties
20,000
Laadcycli
800
Lange batterijduur
De batterij ondersteunt ongeveer 20.000 handelingen en kan 800 keer worden opgeladen.
Ongelooflijk stevig en lichtgewicht Lichtgewicht
Featured with carbon fiber, the EDS TX is lightweight, extremely durable, sleek, and proficient in shock absorption, providing riders with a nimble and comfortable biking experience.
Lightweight
Incredibly Sturdy
Carbon Fiber
IP67  Waterdicht
De IP67-classificatie maakt zelfverzekerd fietsen mogelijk bij regenachtig weer, het oversteken van beekjes en het reinigen van het apparaat, met waterdichte eigenschappen tot 1 meter diepte gedurende 30 minuten, waardoor zorgeloze ritten worden gegarandeerd.
Specificaties
Hydraulische schij
Hydraulische schij
Hydraulische schij
Kabel
Kabel
Kabel
Versnellingshendel
Remhendellengte
140mm
-
140mm
Verstelbereik
8mm
-
8mm
Batterijtype
CR2032
-
CR2032
Snelheidscompatibiliteit
L 1/2s    R 3-14s
-
L 1/2s    R 3-14s
Gewicht
L 209g    R 213g
-
L 209g    R 213g
Achterderailleur (RD)
Snelheidscompatibiliteit
3-14s
-
3-14s
Minimale cassette
10 -11T
-
10 -11T
Maximale cassette
30 -36T
-
30 -36T
Totale bereik van versnellingswissel
36T
-
36T
Gewicht
320g
-
320g
Batterijcapaciteit
800mAh
-
800mAh
Voorderailleur (FD)
Snelheidscompatibiliteit
1/2s
-
1/2s
Kettingbladcompatibiliteit
53T
-
53T
Totale bereik van versnellingswissel
16T
-
16T
Gewicht
187g
-
187g
Kettinghoek
61°-66°
-
61°-66°
Installatietype
Band-On/Braze-On
-
Band-On/Braze-On
Batterijcapaciteit
500mAh
-
500mAh
Hydraulisch schijfrem systeem
Remvloeistof
MINERALE OLIE
-
-
Caliper Mounting Type
For Flat-Mount, Not Compatible with Post-Mount
-
Remschijfcompatibiliteit
140mm/160mm
-
Gewicht
133g(Single)
-
Rembloktype
Compatible with Shimano L04C, LO5A, LO4A
-
Lengte van olieslangen
F: 900mm  R: 1550mm
-
Type olieslangen
BH-40/BH-59
-
1
Versnellingshendel
Remhendellengte
140mm
Verstelbereik
8mm
Batterijtype
CR2032
Snelheidscompatibiliteit
L 1/2s R 3-14s
Gewicht
L 209g R 213g
2
Achterderailleur (RD)
Snelheidscompatibiliteit
3-14s
Minimale cassette
10-11T
Maximale cassette
30-36T
Totale bereik van versnellingswissel
36T
Gewicht
320g
Batterijcapaciteit
800mAh
3
Voorderailleur (FD)
Snelheidscompatibiliteit
1/2s
Kettingbladcompatibiliteit
53T
Totale bereik van versnellingswissel
16T
Gewicht
187g
Kettinghoek
61°-66°
Installatietype
Band-On/Braze-On
Batterijcapaciteit
500mAh
4
Hydraulisch schijfrem systeem
Remvloeistof
MINERALE OLIE
Remmen
Bilateraal Remmen
Remschijfcompatibiliteit
140mm/160mm
Gewicht
133g(Single)
Rembloktype
Compatible with L04A
Lengte van olieslangen
f: 900mm R: 1550 mm
Type olieslangen
BH-40/BH-9061°-66°
1
Versnellingshendel
Remhendellengte
140mm
Verstelbereik
8mm
Batterijtype
CR2032
Snelheidscompatibiliteit
L 1/2s R 3-14s
Gewicht
L 186g R 190g
2
Achterderailleur (RD)
Snelheidscompatibiliteit
3-14s
Minimale cassette
10-11T
Maximale cassette
30-36T
Totale bereik van versnellingswissel
36T
Gewicht
320g
Batterijcapaciteit
800mAh
3
Voorderailleur (FD)
Snelheidscompatibiliteit
1/2s
Kettingbladcompatibiliteit
53T
Totale bereik van versnellingswissel
16T
Gewicht
187g
Kettinghoek
61°-66°
Installatietype
Band-On/Braze-On
Batterijcapaciteit
500mAh
Gebruikershandleiding
PDF
Gebruiksaanwijzing
Installatievideo voor hydraulische schijfremmen
Installatievideo voor kabelremmen
Wat zit er in de doos
Hydraulische Schijfrem Groepsets
Carbon Hand Shift x2
Carbon Achterderailleur x1
Aluminium Voorderailleur x1
Hydraulische schijfremklem x2
Hydraulische oliepijp x2

USB-C Voedingskabel x1

Adattatore USB-C a USB-A x1
Productkaart x1
Reserveonderdelenset x1
Kabelrem Groepsets
Let op: Ondanks hun vergelijkbare uiterlijk is de interne structuur van de schakelaars voor kabelremmen en hydraulische schijfremmen verschillend. Ze zijn niet uitwisselbaar
Carbon Hand Shift x2
Carbon Achterderailleur x1
Aluminium Voorderailleur x1

USB-C Voedingskabel x1

Adattatore USB-C a USB-A x1
Productkaart x1
Remkabels x2

FAQ

Questions about Products

What’s the compatibility of the Wheeltop EDS TX ROAD series?

  • FD: 1 - 2s
  • RD: 3 - 14s
  • FD: total value of gear change range is 16T, teeth numbers of chain wheel is 53T.
  • RD: total value of gear change range is 36T.
  • RD Minimum cassette: 10T(Minimum), 11T(Maximum).
  • RD Maximum cassette: 30T(Minimum), 36T(Maximum).

How’s the battery life?

FD: 500mAh, RD: 800mAh

800 times charge cycles.

Brake ROTOR compatibility?

Available Size: 160mm and 180mm.

Min.TH=150mm, Max.TH≤180mm.

For your safety, please replace any brake discs with a thickness <150mm.

Can I pair a road derailleur with MTB shifters?

  • Currently can't.

Can these groupsets be set as a 1x chainring system?

YES, you could disconnect the FD by following the steps below.

1.Bind the groupset to the Wheeltop APP.

2.Use the "Device shuts down" function within the APP to turn off the system.

3.Utilize a magnetic charging cable to power on the RD(without performing any actions on the FD).

4.Simultaneously press the left and right shifters and wait for the rear derailleur to exit pairing mode (indicated by the blue light no longer flashing).

5.At this point, the RD will be in a state where it is not paired to the FD.

What’s the type of braking pads?

  • Compatible with Shimano L04C, L05A, L04A, BR-RX810, IIPRO-GLYS

Can I order a groupset without the FD?

  • Currently we only sell EDS TX series in complete groupset.

What's the waterproof level?

For EDS-TX

RD: IP67, FD: IP67, Shifters: IP65.

Questions about APP

How to connect to the Wheeltop APP?

1. As the product is charged, it is set to safe mode during transportation, you need to power up the front and back toggles with the magnetic charging cable after receiving the product, after that it can be used normally.

2. Search 'Wheeltop' in Google Play or App Store to get the APP.

3. Open the APP and log in, click the "+" at the bottom of the homepage and turn on the Bluetooth of your cell phone, the APP will automatically search for nearby devices.

4. EDS TX will be displayed in "Bindable Devices", click to bind.

5. After binding, click the Bluetooth icon on the upper right corner, APP will search for the device and connect to it, then you can use the functions normally.

What are the features of the Wheeltop APP?

  1. Check the remaining battery level
  2. Code meter, riding record
  3. Shift mode - front and rear dial cassette number switching, hand shift customized buttons, front and rear dial fine tuning
  4. cassette speed setting
  5. Initial calibration of front and rear dials
  6. Equipment shutdown
  7. Firmware upgrade
  8. After-sales application
  9. Trouble List
  10. Shift mode switching - casual/race
  11. Instructions for use

Questions about Service

Do you have any distributors?

HK: 香港镇洋兄弟单车公司,CHUNGYUNG CYCLE CO.

Malaysia: Zavinci Cycle Hub (M) Sdn Bhd

Thailand: Nattapong Bike

Canada: EZ Bike, DP Motor

France: MANUFACTURE FRANCISE DU CYCLE
+33 02 40 78 23 08
commercial.pna@mfdc.fr

Email service@wheeltop.com for more info.

How can I get after-sale service if I didn’t purchase from the official website.

If you purchase from other channels, the responsibility for the warranty and after-sales service lies with the respective dealers/sellers.
